Cassario Rim Touch Bar Panic Latch PB01-S, Satin Stainless Steel

SKU: 391800100683

The CASSARIO PB01-S Rim Touch Bar Panic Latch is specified for emergency exit doors in commercial, hospitality, residential, and public building projects. Its field-cuttable 1045 mm bar, non-handed configuration, and suitability for timber and steel fire-rated doors make it a practical panic hardware solution for project schedules requiring reliable emergency egress performance.

AED 310
AED 310
MRP is inclusive of all taxes
Color: Satin Stainless Steel
Chat Now My Projects
Note :
* All images shown are for illustration purpose only. Actual product may vary.
* Minor differences in fabric colour, tile shade, wood grain, or finish may occur due to screen settings, lighting, manufacturing variation, or batch differences.
* Product colour may vary slightly due to photographic lighting or your display settings.
* Reasonable dimensional tolerances apply; slight measurement variances are acceptable and industry‑standard. View Product details
Chat Now My Projects
Summary
Brand:
CASSARIO
Collection:
Panic Bar
Material:
Solid Brass
Product Type:
Panic Exit Devices
Origin:
China
Colour:

The CASSARIO PB01-S Rim Touch Bar Panic Latch is an emergency exit device designed for safe, immediate egress in commercial and public buildings. Supplied in a standard 1045 mm length, the bar can be field cut to suit door widths from 650 mm to 1100 mm.

The unit is suitable for single and double door applications, with a non-handed design for flexible installation. Its single-point locking mechanism and touch-bar operation provide controlled emergency exit performance while maintaining a clean satin stainless steel appearance.



Core Features

  • Rim touch bar panic latch
  • Standard length: 1045 mm
  • Field-cuttable to suit opening width
  • Suitable door width: 650–1100 mm
  • Suitable for single and double doors
  • Fire rated for timber and steel doors
  • Immediate exit when the bar is pressed
  • Single-point locking
  • Non-handed installation
  • Satin Stainless Steel finish
  • TDS shows BS EN 1125 and CE marking references
Specifications
Cassario Rim Touch Bar Panic Latch PB01-S, Satin Stainless Steel
Technical
Fire Rating:
BS EN 1125
Mounting Type:
Mounted by Screws
Corrosion & Fire Rating:
Yes
Door Thickness Compatibility:
45mm-55mm
Package Contents:
Panic Bar (1 Nos) Screws (1 Set)
Downloads
The 2D and 3D files(3ds Max software) available are to be used exclusively for planning and must not be used to gauge precise measures for incisions or interlocking. The drawings indicate the sizes required (in mm) in compliance with standard tolerances. For exact sizes, we recommend measuring the finished product.
Specifications
Technical Data Sheet
